Large TFT-LCD Driver


LAPIS Semiconductor offers a section of TFT drivers. Because this product is often customized, contact us for more information on customization.




• Source Driver

Description

Gradation
(bit)

Number of
Outputs*1

I/F

Logic
voltage
(V)

LCD
voltage
(V)

Package

Source Driver

6bit
8bit
10bit

384 to 420
480 to 516
576 to 645
684 to 720
864 to 960

CMOS
RSDS
mini-LVDS

2.3 to 3.6

12
13.5
16.5
18.5

TCP
COF
COG

*1: The number of outputs corresponds to a typical value.



• Gate Driver

Feature

Output
Level

Number of
Outputs*1

I/F

Logic
Voltage
(V)

LCD
Voltage
(V)

Package

Gate Driver

2Value,
others

200 to 270
to 300
to 400

CMOS

2.3 to 3.6V

40
43
45

TCP
COF
COG

*1: The number of outputs corresponds to a typical value.
