APPLICATION
Reed switches are used in a variety of markets and applications.Here we showcase a few of these.
| Reed Switch Applications |
Detection Method |
Recommended ltem |
| Automobile |
Carburetor load sensors |
Detecting the pressure |
ORD324, ORD229 |
| |
Engine oil level、Fuel tank level、Brake fluid level、Window washer fluid level、Power steering fluid level |
Liquid amount detecting |
ORD324, ORD228VL, ORD229
|
| |
Seat belts、Sunroofs、Key lock security、Intermittent wipers
|
Detection position |
ORD324, ORD228VL, ORD229 |
| |
Power seats |
Detecting rotation |
ORD324 |
| |
Defective lamp detection sensors |
Induced current |
ORD2211 |
| |
Air bag sensor |
Induction shocks |
Shock sensor |
| |
Engine oil、Radiators |
Temperature sensing |
ORD221 |
| |
|
|
|
| Household Appliances |
Humidifiers、Fan heaters |
Detection fluid volume |
ORD324, ORD229 |
| |
Flow sensors of hot water heaters |
Pressure sensitive |
ORD324, ORD229 |
| |
Security system sensors、Mobile phones、Rice cookers)、Electric toothbrushes (Switches)、Shavers (Switches) |
Detection position |
ORD324 |
| |
Gas meters、Water meters、Electric power meters、Hot water heaters |
Detecting rotation |
ORD228S-1, RA series |
| |
Thermos-type hot water dispensers、Rice cookers |
Temperature sensing |
ORD324, ORD229 |
| |
Fan heaters |
Induction wind pressure |
ORD324, ORD229 |
| |
|
|
|
| Health supplies / Entertainment |
Exercise machines、Electric fishing reels 、Pedometers |
Detecting rotation |
ORD324, ORD211, ORD213 |
| |
Pedometers |
Induction shock |
ORD324, ORD211, ORD213 |
| |
Exercise machines、Thermometers 、Electric fishing reels |
Detection position |
ORD324, ORD211, ORD213 |
| |
Pachinko (Japanese pinball) machines |
Induction by |
ORD324, ORD2212 |
| |
|
|
|
| Industrial equipment |
Pneumatic cylinders、Vending machines |
Detection position |
ORD221, ORD314, ORD219 |
| |
Reed relays ( semiconductor testers, digital devices, automatic measurement equipments, general control systems, process control, telephone modems, vending machines ) |
Circuit control |
ORD324, ORD228VL, ORD211, ORD314 …etc |
| |
|
|
|
| Security |
Door open/close status、Residence locking |
Detection position |
ORD324, ORT551 |
| |
|
|
|
